Main function:

1.Sofa and furniture cushions for testing springs and spring framework and spring package cushion durability and endurance.

2.The pressure conditions can be repeatedly pressing the preset test period can be pre-set to the number of stops automatically.

3.The machine is designed for sofa spring frameworks and spring package, sponge test equipment, which can meet the requirements of the following three tests

1)Stress conditions durability testing conducted according to a pre-set by repeatedly pressing the test, the cycle can be pre-set to the number of stops automatically.

2)Compression volume and pressure relationship detection process by pre-set itineraries under pressure, in place to stop. Read the itinerary spring force on the pressure gauge, display itineraries value on the display.

3)The specific pressure of the spring compression volume detected platen press to set the pressure after the stop, the length of the compressed itinerary pressure value on the display.

Technical parameter:

a.The machine maximum pressure = 100 kg, maximum push itineraries 150 mm.

b.Pressure sensor Accuracy: 0.3% FS

c.Itinerary Accuracy:. ± 0.2 mm

d.Power: 220 volts, 300 watts of power
