UV Aging Test Chamber can simulate the ultraviolet ray in the sun, rain and dew to damage the material, UV using UV lamp simulate the effect ultraviolet ray of sunlight, cold rain and dew. Being tested materials are placed in a certain environment which the light and moisture are alternating.
Corresponding Standard
Accord with ASTMG53-77, GB, GJB, MIL, ASTM, CNS, IEC, JIS, AATCC, DIN, Fed Test, BS, SAE
Main Functions
The materials are tested for several days or weeks, you can know the damage types include: bleaching, discoloration, loss of light, powder, crack, turbidity, bubble-based, embrittlement, strength decline and oxidation.
Technical Parameter:
| Model | HZ-2008 UV aging test chamber |
| Lamps Quantity | UV Lamp 8pcs, spare lamp: 4pcs, (ATLAS, UVA340, UVB313, UVC351) |
| Recorder | Option |
| Radiometer | Option |
| UV Temperature | From 45 °C to 70 °C |
| Black temperature | From 40 °C to 60 °C |
| Testing Capacity and sample size | 48 piece (75 x 150mm) / 50 piece (75 x 150mm) |
| Water and Consumption | Distilled water, 8 liters / day |
| Dimension (W x D x H) | 137 x 53 x 136cm |
| Weight | 136kg |
| Power | 1 ψ, 120V/60Hz, 16A or 230V/50Hz, 9A, 1800W (max) |
